Designed by ATPL
AUTOTEC
Manufacturers of Process Control Instruments

FEATURES :-
ALARM ANNUNCIATOR

Type : Microcontroller Based.
Display device : 4 Nos. Super bright LEDs per window.
No. of windows : 8 to 40 in different configurations in a single unit.
Window color : Standard Color-RED.
Flash Rate : Fast-60 Flashes/min, Slow-30 Flashes/min.
Legend : Backlit photo film (user specified)
Input Signals : Opto-isolated.
Input contact type : NO/NC Field selectable through DIP Switches.
Interrogation Voltage : 24V DC.
Output contacts : 1No. for Fault Hooter,
Contact Rating : 3 Amps at 240V AC (resistive)
Operational Sequence : Auto/Manual/First-up selectable at site. Any custom-made
sequence can be built-in optionally
Power Supply : Universal SMPS - 90 to 260 V AC / 110 to 300 V DC
